* Please name the model No. when negotiation.

* End Flange Acc. To JIS 10K, ANSI 150 LBS, or DIN PN16.

* Working Temperature: 180℃

* Max. Temperature: 220℃

* Test Pressure: Body 20kgf/cm2 (Hydrostatic)

* Primary Pressure: 1kgf/cm2 – 10kgf/cm2 (PR-3AF)

Material:

Model:

PR-3AF

PR-304F

Body Val Top Cap

IRON

SUS 304

Bottom Cover

IRON

SUS 304

Lower Gasket

ASBESTOS

ASBESTOS

Diaphragm Disc

AIS-301

AIS-301

Seat

BC3

CF8

Spring

SUP-6

SUP-6

Spring Seat

SUS 304

SUS 304

Piston/Cylinder

BC3

CF8

Packing

PTFE

PTFE

Screen

SS304

SS304

Adjust Scr. Nut

BRASS

BRASS

Bolt

SS41

SUS 304

 DIMENSION

mm

 Size

inch

1/2

3/4

1

1.1/4

1.1/2

2

2.1/2

3

4

5

6

mm

15

20

25

32

40

50

65

80

100

125

150

   L

155

155

165

195

195

225

250

290

330

410

410

   H1

74

74

74

99

99

116

125

135

153

195

195

   H2

260

260

260

280

280

310

322

325

370

540

540
